SSM - SSM/HP Forestry Tiller


SSM - SSM/HP Forestry Tiller
For Sale
Please phone us for pricing

SSM - SSM/HP Forestry Tiller



Specifications

New/Used:  New
Type:  Forestry Tiller
Manufacturer:  FAE Group
Model:  SSM - SSM/HP

Additional Details:

Forestry tiller for tractors between 150 and 300 HP with a max grinding diameter of 50 cm/16".
This Heavy Duty tiller is designed and built to be used with medium to high power tractors.
The "HP version" is equipped with a reinforced transmission and can grind stumps up to 50 cm/20"
in diameter to a depths of 40 cm/16", for excellent depth soil reclamation.
The soil is thus ready for planting without further processing.
Multiple tooth options available for different environments.

The standard equipment includes:

  • friction clutch on side PTO
  • PTO shaft with cam clutch
  • gearbox with freewheel
  • transmission with side gearbox
  • hydraulic hood
  • welded steel counter-blades
  • flat pressed welded steel protection counter-blades
  • enclosed machine body
  • centralized greasing hub
  • hydraulic top link
  • Z style self ranging system of the PTO drive shaft/gearbox
  • inside lateral protections
  • bigger transmission for tractors up to 360-400 HP (SSM/HP 200, 225 and 250)
  • protection chains

Available on demand: W style self aligning device between PTO drive shaft/gearbox, dozing blade (not compatible with roller), hydraulic controlled roller (not compatible with dozing blade), multiple tooth options.
